Gigabyte GTX 1070 Windforce OC 8G

---

Features
Power by GeForce® GTX 1070
Integrated with 8GB GDDR5/ 256bit memory
WINDFORCE 2X with Blade Fan Design
Support up to 8K display @60Hz
Build with 6+2 power phases

Core Clock
Boost: 1771 MHz/ Base: 1582 MHz in OC Mode
Boost: 1746 MHz/ Base: 1556 MHz in Gaming

Graphics Processing: GeForce® GTX 1070
CUDA® Cores: 1920
Process Technology: 16 nm
Memory Clock: 8008 MHz
Memory Size: 8 GB
Memory Type: GDDR5
Memory Bus: 256 bit
Card Bus: PCI-E 3.0 x 16
Digital max resolution: 7680x4320
Multi-view: 4
Card size: H=37 L=280 W=131 mm
PCB Form: ATX
DirectX: 12
OpenGL: 4.5
Recommended PSU: 500W
Power Connectors: 8 pin*1
Output:
Dual-link DVI-D *1
HDMI-2.0b*1 (Max Resolution: 4096x2160 @60 Hz)
Display Port-1.4 *3 (Max Resolution: 7680x4320 @60 Hz)
SLI Support: 2-way SLI HB
